The user can switch the firmware themselves, between Serial and Application firmware, using the ER8x5 Converter and Updater Software (download from here and find instructions in the video and manuals). You must have the Serial firmware installed on the C4D hardware unit. Do not use the C4D Configurator Software when the ER815 and ER825 are configured with applications firmware, or when using the ER225.ĬE-part configuration. Selecting C4D Settings The C4D settings (amplitude, frequency and headstage gain) should be selected in the PowerChrom software.
You should connect the modified EC071 Trigger cable, from the CE instrument to the I2C connector at the back of the ER8x5 unit, so that the Agilent ChemStation software sends a message to PowerChrom software to trigger start recording. Set up the hardware and PowerChrom software as detailed in the manuals.
You must also have the Application firmware installed on the C4D hardware unit. You must have PowerChrom software to do this. If you are using the ER815 or ER825 units, you have a choice of recording the data in either PowerChrom software or Agilent ChemStation software. You should also ensure that the C4D hardware unit is connected to an electrical socket which is grounded. This is to prevent the high voltage inside the capillary from shorting through the headstage and its cable, which are both electrically grounded. You should ensure that the C4D headstage and its flat grey cable are at least 1 cm away from the capillary as it loops inside the cartridge. This is to ensure that the high voltage doesn’t arc from the background electrolyte inside the capillary, through the thin wall of the capillary, to the headstage and on to the C4D hardware, which could damage the equipment. Simply thread the capillary through the channel in the side of the C4D headstage and fix in place.Įnsure that you position the C4D headstage near the end of the capillary that is grounded, away from the end of the capillary where the high voltage is applied. It’s easy to mount the C4D headstage inside the Agilent CE cartridge. Installing the C4D Headstage in the Agilent Cartridge PowerChrom software records the data from both detectors. The analog output of the Agilent UV-Visible detector is connected to the analog input of the ER225. ER225 C4D Data System can also be used.The ER825R model includes PowerChrom software and can record the signal from both C4D and UV detectors. ER825R Two Channel C4D Detector, can also be configured by the user to use either PowerChrom or third-party software like Agilent ChemStation.The ER815R model includes PowerChrom software to record the C4D signal. The analog output from the ER815 can be connected to the input of the Agilent CE, so the ChemStation software records data from both detectors. ER815 C4D Detector can be configured by the user to use either PowerChrom or third-party software like Agilent ChemStation.Use the ET120 C4D Headstage and select either the: You can use either the eDAQ PowerChrom software or Agilent ChemStation software. The data from both C4D and UV-Visible detectors can be recorded and displayed in real time. EC020 Standard Test Solutions for C4D Applications.Trigger cable: modified version of EC071 Trigger cable with DB9 male (Agilent Remote) to DB9 female (ER815 I2C), available on special order.Signal cable: EC001-4 BNC to BNC Cables.Agilent 7100 CE instrument with ChemStation software.
ET120 C4D Headstage for Capillary Electrophoresis.ER825R Two Channel C4D Detector to record both C4D and UV signals in PowerChrom or ChemStation software.ER815R C4D Detector to record only the C4D signal in PowerChrom or ChemStation software, or.ER815 C4D Detector to record both C4D and UV signals in ChemStation software,.The eDAQ C4D can be connected to the Agilent 7100 CE instrument, providing contactless conductivity detection for the instrument.īoth the C4D headstage and UV detector can be connected to the capillary at the same time, enabling both types of detection to be performed with a single sample injection. 4 Installing the C4D Headstage in the Agilent Cartridge.
